Jeep Renegade (2014-2023): service and repair manuals

Jeep Renegade (2015-2018) - Gasoline & Diesel | Haynes Repair Manual

NEW

Haynes Repair Manual for the Jeep Renegade models BU, BV and BQ.

Gasoline engines:
- 1.4 Turbo MultiAir 160 (engine code EAM)
- 2.4 MultiAir (ED6).

Additionally covers online (accessible via QR codes printed in the book):
- 1.6L Eco Turbo Diesel (EJK)
- 1.6L eTorque gasoline engine (EJH).

Model years: 2015-2018.

This manual on the Jeep Renegade describes maintenance and repair of the gasoline engines (timing gear, belts, valves, camshaft, cylinder head, oil pump, seals and crankshaft), as well as the cooling system, the heater, the fuel system, the exhaust, the starting and charging system.
Covers also work on the rest of the vehicle, including clutch, gearbox (removal and installation), driveshafts, braking system, suspension, steering gear, body, interior and the electrical system.

• Step-by-step instructions with hundreds of illustrations.
• For American and Canadian models.
• Based on a complete strip-down and rebuild.
• Complete with a maintenance schedule, technical specifications, torque wrench settings and troubleshooting tables.

Product details

More information on the American Haynes Repair Manuals

Jeep Renegade (2019-2023) - Gasoline models | Haynes Repair Manual

NEW

Haynes Repair Manual for the Jeep Renegade BU, BV and BQ models.

Gasoline engines:
- 1.3 L (engine code EYF)
- 1.4 L (EAM)
-2.4 L (ED6 and ED8).

Model years: 2019-2023.

This manual on the Jeep Renegade describes maintenance and repair of the gasoline engines (timing gear, belts, valves, camshaft, cylinder head, oil pump, seals and crankshaft), as well as the cooling system, the heater, the fuel system, the exhaust, the starting and charging system.
Covers also work on the rest of the vehicle, including clutch, gearbox (removal and installation), driveshafts, braking system, suspension, steering gear, body, interior and the electrical system.

• Step-by-step instructions with hundreds of illustrations.
• For American and Canadian models.
• Based on a complete strip-down and rebuild.
• Complete with a maintenance schedule, technical specifications, torque wrench settings and troubleshooting tables.

Product details

More information on the American Haynes Repair Manuals

Jeep Renegade - Diesel 2.0 JTD (120 et 140 ch) (depuis 09/2014) | Revue Technique Automobile RTA HS24

Revue Technique Automobile (RTA HS24) covering the Jeep Renegade diesel models.

Diesel engines:
- 2.0 JTD 120 (1956 cc, 88 kW/120 hp)
- 2.0 JTD 140 (1956 cc, 103 kW/140 hp)

Production years: since 09/2014.

This Revue Technique for the Jeep Renegade Diesel describes extensively maintenance and repair of the 2.0 JTD diesel engines (including timing gear, cylinder head, lubrication, coolant pump and fuel system).
Covers also work on the clutch, transmission, driveshafts, steering system, suspension, wheel hubs, brakes and electric equipment.
Special attention for the body (bumpers, headlamps, interior trim, removable parts, windows and window mechanisms, glued parts, welded parts and body check on the straightening bench).

• Includes adjustment data and torque wrench settings.
• An integral owner's handbook gives information on operation and daily maintenance.
• Full colour.

Product details

More information on the Revue Technique Automobile manuals
