Peugeot 505 (1979-1992) repair manuals - petrol and diesel
A repair manual for your Peugeot 505 (1979-1992)? Here are detailed shop manuals for DIY service and repairs on Peugeot cars.
They offer clear instructions for maintenance, troubleshooting, and parts replacement.
Are you also looking for parts or accessories for your Peugeot? Then try our Parts Finder.
Peugeot 504 & 505 Diesel Engines - 2.0, 2.1, 2.3 & 2.5 litre (1974-1990) | Haynes Service and Repair Manual
Haynes Repair Manual covering the Peugeot diesel engines (including turbo diesel engines), installed in the Peugeot 504 and 505. Also useable for the Peugeot 604 Diesel.
Types:
- 2.0 L (1948 cc)
- 2.1 L (2112 cc)
- 2.3 L (2304 cc)
- 2.5 L (2498 cc).
Production years: 1974-1990.
Product details
| Author: | Ian Coomber |
|---|
| Details: | 159 pages, 27 x 21 cm / 10.6 x 8.25 in, paperback |
|---|
| Illustrations: | hundreds of photos and drawings |
|---|
| Publisher: | Haynes Publishing (GB, 1991) |
|---|
| Series: | Haynes Service and Repair Manual (1607) |
|---|
| ISBN: | 9781850106074 |
|---|
More information on the Haynes Repair Manuals
Peugeot 505 - 4-cylinder Petrol (1979-1989) | Haynes Service and Repair Manual
Haynes Repair Manual covering the Peugeot 505 saloon, estate and Familiale, powered by 4-cylinder petrol engines.
Petrol engines:
- 1.8 L (1796 cc, engine code XM7A)
- 2.0 L (1971 and 1995 cc, XN1/A and ZEJK)
- 2.2 L (2165 cc, ZDJL).
Production years: 1979-1989.
Exclusions: This manual does not cover the V6 petrol engine or the diesel engines.
This Haynes manual for the Peugeot 505 describes service and repair of the 4-cylinder petrol engines (timing gear, belts, valves, camshaft, cylinder head, oil pump, seals and radiator).
It also includes procedures for the heater, fuel system, exhaust, starting and charging system. Additionally, it describes work on the clutch, gearbox, driveshafts, braking system, suspension, steering gear, body, interior, and electrical system.
- Step-by-step instructions with hundreds of detailed photos guide you through every job.
- Based on a complete vehicle strip-down and rebuild.
- Includes a maintenance schedule, technical specifications, torque wrench settings, and troubleshooting tables.
- Clear and detailed wiring diagrams.
Product details
| Details: | 296 pages, 27 x 21 x 1.8 cm / 10.6 x 8.25 x 0.71 in, paperback |
|---|
| Illustrations: | hundreds of photos and drawings |
|---|
| Publisher: | Haynes Publishing (GB, 1989) |
|---|
| Series: | Haynes Service and Repair Manual (0762) |
|---|
| ISBN: | 9780856967627 |
|---|
More information on the Haynes Repair Manuals
Peugeot 505 (ab 1982) | Bucheli Reparaturanleitung
Bucheli Reparaturanleitung for service and repair of the Peugeot 505, saloon and Familiale.
Versions: GL, GR, SR, GTI and Turbo Injection.
Petrol engines: 1.8 L, 2.0 L and 2.2 L.
Production years: since 1982.
![Pages of the book [0903] Peugeot 505 (ab 1982) (1)](../afb/details/PP20911.jpg)
This Bucheli repair manual for the Peugeot 505 provides detailed instructions for work on the petrol engines (removal - refitting, crankshaft, connecting rods, pistons, distribution, valves, oil pump, cooling, fuel system).
Covers also the clutch, gearbox (only removal and installation), driveshafts, steering system, front and rear suspension, brakes, electrical system and the exhaust.
- Includes comprehensive technical data and torque wrench settings.
- Clear wiring diagrams.
- Reprint of the 3rd edition (1988).
Product details
| Details: | 168 pages, 28 x 21 cm / 11 x 8.25 in, paperback |
|---|
| Illustrations: | numerous photos and drawings |
|---|
| Publisher: | Bucheli Verlag (CH, 2017) |
|---|
| Series: | Bucheli Reparaturanleitung (903-904-905) |
|---|
| ISBN: | 9783716817360 |
|---|
More information on the Bucheli repair manuals
Peugeot 505 (ab 5/1979) | Bucheli Reparaturanleitung
Bucheli Reparaturanleitung for service and repair of the Peugeot 505.
Versions: GL, GR, SR, TI, STI.
Petrol engines:
- 2.0 L (1971 cc, carburettor, engine code XN1)
- 2.0 L (1995 cc, injection, ZEJ)
- 2.2 L (2165 cc, injection, ZDJ).
Production years: since 5/1979.
![Pages of the book [0720] Peugeot 505 (ab 5/1979) (1)](../afb/details/PP20812.jpg)
This Bucheli repair manual for the Peugeot 505 provides detailed instructions for work on the petrol engines (removal - refitting, crankshaft, connecting rods, pistons, distribution, valves, oil pump, cooling, fuel system).
Covers also the clutch, gearbox (only removal and installation), driveshafts, steering system, front and rear suspension, brakes, electrical system and the exhaust.
- Includes comprehensive technical data and torque wrench settings.
- Clear wiring diagrams.
- Reprint of the 3rd edition (1984).
Product details
| Details: | 185 pages, 28 x 21 cm / 11 x 8.25 in, paperback |
|---|
| Illustrations: | numerous photos and drawings |
|---|
| Publisher: | Bucheli Verlag (CH, 2016) |
|---|
| Series: | Bucheli Reparaturanleitung (720-721-722) |
|---|
| ISBN: | 9783716816288 |
|---|
More information on the Bucheli repair manuals
